Multiple sealing insert, metric
Item no. 2029693 | EAN 4012195036319
- Product description
-
Product descriptionUse to insert multiple thin cables in the V-TEC VM cable glands, is replaced with the simple sealing ring of the cable gland.
-
- Technical data
-
Technical data
Colour Black CO₂ Footprint (GWP) Cradle-to-Gate 0,0139 kg CO₂e / 1 Piece Dimension VM32,2X8 Dimension D 8 mm Dimension D1 25,1 mm Dimension H 13,4 mm External diameter 25,1 mm Hole diameter 8 mm Inner diameter 8 mm Material Rubber mixture Number of drill holes 2 Protection rating IP68 Suitable for metric thread dimension 32 Thickness 13,4 mm Version for Miscellaneous - All types
- Downloads
-
Data sheet 107 C VM 32 2x8 / 2029693 , 0.20MB , pdfEU declaration of conformity 107 C VM 32 2x8 / 2029693 , 0.10MB , pdfEU declaration of conformity EU declaration of conformity ,UK Declaration of Conformity 107 C VM 32 2x8 / 2029693 , 0.09MB , pdfREACH Declaration of conformity 107 C VM 32 2x8 / 2029693 , 0.12MB , pdfRoHS Declaration of conformity 107 C VM 32 2x8 / 2029693 , 0.12MB , pdfMounting instructions Mounting instructions, V-TEC VM.. ..x.. , 2.00MB , pdf
