Trunking connector and joint cover

Trunking connector and joint cover

Type GEK-KS45-3 | Item no. 6116163 | EAN 4012195391647

Show all variants
Item no. / Type
6116163 / GEK-KS45-3
Colour
Pure white; RAL 9010

Smallest selling unit: 0 translation missing

DescriptionTechnical dataDownloadsVariants

Description

Joint cover for smooth connection of trunking segments.

  • Verband der Elektrotechnik, Elektronik, Informationstechnik e.V., Germany
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • UKCA declaration of conformity
  • CO₂ footprint (PCF)
  • Packaging without plastic
  • Packaging made entirely from recycled cardboard

Technical data

Technical data

Halogen-freeno
Protection ratingIP30
Protection rating IK codeIK08
for duct width165 mm
for trunking height53 mm
ShapeUniversal
Version forTrunking cut cover
Fastening typeMiscellaneous
Cover width45 mm
Permitted temperature range, max.60 °C
Permitted temperature range, min.-15 °C
MaterialPolyvinylchloride
ColourPure white; RAL 9010
CO2 Footprint (GWP) Cradle-to-Gate0,0406 kg CO2e / 1 Piece

Downloads

0 selected

Data sheet (2)
Catalogues & Flyers (1)
Declarations (3)
Certificates (2)
Instructions and Aid (1)
Product images (2)
3D data downloads (1)
Tender specifications (2)

Variants

GEK-KS45-3
Item no.
6116163
Colour
Pure white; RAL 9010
