Plug-in arrester V10 280 V

Plug-in arrester V10 280 V

Type V10-C 0-280 | Item no. 5093402 | EAN 4012195012825

Show all variants
Item no. / Type
5093402 / V10-C 0-280
Protection rating
IP20
Pole version
1

Smallest selling unit: 1 piece

DescriptionTechnical dataDownloadsVariants

Description

Surge arrester, type 2+3 to EN 61643-11

• Plug-in upper part; upper part can be separated from base without tools
• Incl. thermal and dynamic cut-off unit and visual display of defects
• High current conductivity and long service life
  • 5-year warranty
  • Communautés Européennes, EC declaration of conformity according to EC directives
  • EurAsian Conformity
  • Transition from LPZ 1 to LPZ 3
  • Protection device to DIN EN 61643-11 or IEC 61643-11
  • CO₂ footprint (PCF)
  • Packaging without plastic

Technical data

Technical data

Network formOther
Blow-outno
Signalling on deviceVisual
Protection ratingIP20
Remote signallingno
Test class, type 2yes
Nominal voltage AC (50/60 Hz)230 V
Maximum continuous voltage AC280 V
Nominal discharge current (8/20 µs)10 kA
Pole version1
Installation typeOn basic element
Max. mains-side overcurrent protection125
Version for1-pole
Operating temperature, min.-40 °C
Operating temperature, max.80 °C
SPD to IEC 61643-1Class II+III
SPD to EN 61643-11Type 2+3
Lightning protection zone LPZ1→3
Maximum discharge current (8/20 μs)20 kA
Response time<25 ns
Maximum back-up fuse125 A
Permitted temperature range, min.-40 °C
Permitted temperature range, max.80 °C
Dimension280V
CO2 Footprint (GWP) Cradle-to-Gate0,2496 kg CO2e / 1 Piece

Connectivity options

Arrester surge current (8/20 µs) [total]10 kA
Conductor cross-section, rigid (single-wire/multiwire), min.2,5 mm²

Downloads

0 selected

Data sheet (1)
Catalogues & Flyers (2)
Declarations (3)
Certificates (1)
Instructions and Aid (1)
Product images (2)
Tender specifications (2)

Variants

V10-C 0-280
Item no.
5093402
Protection rating
IP20
Maximum continuous voltage AC
280
Pole version
1
